Serial EEPROM Handheld Programmer
Hand Held Programmer for Serial EEPROMs
A very simple to use HandHeld Programmer that is loaded from the PC using the LPT Starter Kit. Once the programmer is loaded with device information and data, then you just plug it into your target...
Shipping to United States
Recorded Airmail: $15.00
Fedex Express: $29.00
Recorded Airmail: $15.00
Fedex Express: $29.00
Order Code
HH0120EE-P
HH0120EE-P
Price: $129.00
In Stock
Related Products
| Product Details |  |
Please purcase USB version instead
A very simple to use HandHeld Programmer that is loaded from the PC using the Starter Kit. Once the programmer is loaded with device information and data, then you just plug it into your target circuit and press the big red button.
Programmer can power target device, so it can be used to program EEPROMs that are separate from other circuitry e.g. tags for QA purposes, or EEPROMs included in a circuit e.g. attached to a microcontroller
Features
Device Support
All 24C I2C and 25C SPI family EEPROMs are supported. The serial EEPROM handheld Programmer has these device support features:Supports low voltage variants
Address bus to select an individual device in multiple circuits
User selectable page size as the same device from different manufacturers, or even variants of the same device, can have different programming page sizes
Microcontroller Reset line to isolate microcontrollers connected to EEPROMs - low or high reset polarity
Programmer has up to 32KB data size
Contact support for information on other device families
supports 24C and 25C serial EEPROMs from Atmel, Microchip, ST, Catalyst and others
Starter Kit
You need one Serial EEPROM Programmer Starter Kit to load as many programmers as you like from the PC. Once the serial eeprom programmer is loaded it is completely portable.
Physical
Related Products
Serial EEPROM Handheld Programmer Starter Kit - You need one starter kit to load the programmer
USB Serial EEPROM Handheld Programmer Starter Kit - You need one starter kit to load the programmer
Universal 9V PSU (wall transformer) with EU, UK, US and Australian plug fittings, 90-250VAC, 47-63Hz.
10-WAY to 6-Way DIL adapter
10-WAY to 6-Way Flying Lead adapter
Hand Held Programmer for Serial EEPROMs
A very simple to use HandHeld Programmer that is loaded from the PC using the Starter Kit. Once the programmer is loaded with device information and data, then you just plug it into your target circuit and press the big red button.
Programmer can power target device, so it can be used to program EEPROMs that are separate from other circuitry e.g. tags for QA purposes, or EEPROMs included in a circuit e.g. attached to a microcontroller
Features
- Compact, portable and easy to use
- One button operation
- Supplied with 9V PP3 battery
- Power supply connector (2.1mm, centre positive)
- Programmer can power target up to 150mA or draw power from target
- Supports low voltage and 5V serial EEPROMs
- Loaded from PC using simple Wizard Software and PC adapter supplied with starter kit - supports Windows 95, 98, NT, 2000, XP. ME
- Erase, program, verify and lockbits supported
- Includes Microcontroller reset line to isolate MCUs in circuit
- Non-volatile memory keeps data even with flat battery
Device Support
All 24C I2C and 25C SPI family EEPROMs are supported. The serial EEPROM handheld Programmer has these device support features:
Starter Kit
You need one Serial EEPROM Programmer Starter Kit to load as many programmers as you like from the PC. Once the serial eeprom programmer is loaded it is completely portable.
Physical
- Dimensions: 106 x 58 x 25mm, 4.5 x 2.5 x 1 inches
- Includes 9V PP3 battery
- Power supply requirements: 9V regulated, 2.1mm barrel connector, centre positive - see below for suitable power supply.
Related Products
Serial EEPROM Handheld Programmer Starter Kit - You need one starter kit to load the programmer
USB Serial EEPROM Handheld Programmer Starter Kit - You need one starter kit to load the programmer
Universal 9V PSU (wall transformer) with EU, UK, US and Australian plug fittings, 90-250VAC, 47-63Hz.
10-WAY to 6-Way DIL adapter
10-WAY to 6-Way Flying Lead adapter
|
Ordering Information
| Ordering Information | Order Code: HH0120EE-P | Price: $129.00 |
| Shipping to United States: | Recorded airmail - $15.00 | Fedex Express - $29.00 |
|
